◆可选带以下功能 Optional with following function:
→全波调速 Full-wave s peed control
→半波调速 Half-wave speed control
→On-Off通断功能带可变电阻输出 On-off version with Passive linear potentiometer
◆可选带以下附件 Optional with the accessories as follows:
→初始电压微调节旋钮 Knob for adjusting start voltage
→可控硅外置适合更大电流并可附带散热片
→External Triac version for high currents additional with heat sink
→机械耐久寿命 Mechanical life endurance
≥1E5
→电气耐久寿命 Electrical lifeendurance≥5E4
→最大电流 Max. current at 250V8A
→最大电流 Max. current at 125V12A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP40
→开关内部电子部分在相应使用中一并做过相关测试，本开关适合做二类器具开关使用。
→The electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class II.
◆输入端/输出端 Input side/Output side:
→导线端子 Wires terminals AWG14 ~ AWG18.
